Alinco - DR-735E

Product code: 1219
Barcode: 4969182341102

The Alinco DR-735E can receive simultaneous TX/RX within 144/440 MHz bands as well V/V and UU. Freely and separately selectable display colors for TX, RX and Stand-by! Fully independent frequency, audio level and squelch knobs for right and left VFO's make it seem more like operating two mono-band radios rather than a dual-band transceiver. Large heatsink and quiet fan for stability while operating. Two speaker ports located on the back of the radio allow you to separate signals by both right and left sides or by internal or external speakers using audio from a single external source.

Frequency range: TX/RX: 144-146 MHz / 430-440 MHz
Shipped next business day
€314.01 (314.01 excl. 0% VAT)

Features

  • Display: Yes with multicolor backlight
  • DTMF: Yes, encode and decode
  • 2-tone/5-tone: Yes
  • High/low power selection: Yes
  • DCS: Yes, encode and decode
  • CTCSS: Yes, encode and decode
  • Program: Yes, by computer

Electrical data

  • Frequency step: 5 kHz / 6.25 kHz / 8.33 kHz / 10 kHz / 12.5 kHz / 15 kHz / 20 kHz / 25 kHz / 30 kHz / 50 kHz / 100 kHz /
  • Channels: 1000 + 100 (dual)
  • Wide and narrow bandwidth selection: Yes
  • Operating temperature: -10℃ to +60℃

Transmitter

  • Power output (Watts): VHF/UHF: 5 / 20 / 50 Watts
  • Modulation limit: 16K0F3E / 11K0F3E
  • Adjacent channel power: ≥60 dB
  • Spurious Emission: ≥60 dB
  • Frequency stability: ±2.5 PPM
  • Frequency deviation: Wide: ±5 kHz / Narrow: ±2.5 kHz
  • Hum & Noise: Wide: ≥40 dB / Narrow: ≥34 dB

Receiver

  • Sensitivity: -16 dBu for 12 dB SINAD
  • Spurious rejection: ≥70 dB
  • Hum & noise: Wide: ≥45 dB / Narrow: ≥40 dB
  • Audio power output: 2 Watts @10%
  • Receiver circuitry: Double conversion super heterodyne
  • Selectivity: -6 dB: 12 kHz / -60 dB: 24 kHz
  • Squelch sensitivity: -16 dBu
  • Inter modulation: 60 dB
  • Intermediate frequency VHF MAIN / UHF SUB: 1st 21.7 MHz / 2nd 450 kHz
  • Intermediate frequency UHF MAIN / VHF SUB: 1st 30.85 MHz / 2nd 455 kHz

Mechanical data

  • Length: 140 mm
  • Height: 40 mm
  • Width: 188 mm
  • Weight: 1300 gram
  • Antenna connector: UHF (PL) female (SO-239)
  • Mike connector: 8 pin connector

Inside the box

  • Transceiver: Yes
  • Microphone: Yes
  • Mounting bracket: Yes
  • Mounting parts: Yes
  • DC power cable: Yes
  • Installation manual: English
  • DC cable: Yes
