Sirio - SCO-2-6 N-f

Product code: 211052000

Factory code: 2110520.00

Base station antenna working on 1.92 - 2.17 GHz conceived for UMTS system. The radiant element is made of PTFE PCB to guarantee high power and low losses and it is protected by a fiberglass tube. It is supplied with an aluminium bracket for an easy installation on the mast.

Frequency range: 1.92 - 2.17 GHz

Shipped next business day

€49.95 (41.28 excl. 21% VAT)

Electrical data

• Electrical type: 3x 1/2 λ colinear
• Gain: 3.9 dBd, 6 dBi
• VSWR: TX: ≤ 1.8 / RX: ≤ 2.6
• Maximum continuous power: 20 Watts (CW)
• Impedance: 50 Ohm
• Polarization: Linear vertical

Mechanical data

• Materials: Aluminium, chromed brass, fiberglass, PCB
• Mast Ø: 35 - 54 mm
• Max wind resistance: 200 km/h
• Height: 400 mm
• Weight: 360 gram
• Mounting type: On mast
• Antenna connector: N-female, gold plated central pin

Inside the box

• Antenna: Yes
• Mounting parts: Yes
• Installation manual: English

Downloads

• Datasheet: Id 300 07 05 2012 sco 2 6
