Sirio - WY 140-6N

Product code: 2113601140
Factory code: 2113601/140
Barcode: 8056182113696

Directional base station antenna for 140 - 160 MHz, no tuning required. Conceived by using an innovative feed system studied and applied to have highly symmetrical radiation pattern in both planes (E and H). It's completely computer designed to get high performances of gain and front-to-back in the working band. All aluminium parts are protected by anodized treatment, hardware are of stainless steel of zinc plated steel, mounting bracket is of extruded aluminium for the best strength and the connector is placed in rear position for an easily access. To increase the antenna gain please install it in vertical stacked array.

Frequency range: 140 - 160 MHz
Shipped next business day - Stock: 4
€168.95 (139.63 excl. 21% VAT)

Electrical data

  • Electrical type: 6 elements Yagi
  • Gain: 8.35 dBd, 10.5 dBi
  • VSWR: ≤ 1.5
  • Maximum continuous power: 200 Watts (CW)
  • Impedance: 50 Ohm
  • Polarization: Linear vertical / Linear horizontal /

Mechanical data

  • Materials: Anodized aluminium, chromed brass, thermoplastic UV stabilized, EPDM rubber
  • Mast Ø: 35 - 52 mm
  • Max wind resistance: 120 km/h
  • Height: 1085 mm
  • Width: 2010 mm
  • Weight: 2440 gram
  • Mounting type: On mast
  • Antenna connector: N-female
  • Boom diameter Ø: 32 mm
  • Dipole diameter Ø: 24 mm
  • Element diameter Ø: 12 mm
  • Tuning radius: 1940 mm

Inside the box

  • Antenna: Yes
  • Mounting parts: Yes
  • Installation manual: English
