Midland - HM135 S

Midland - HM135 S

Product code: 1004
Factory code: G934

The HM135 S is a VHF professional radio extremely versatile, IP54 compliant case and MIL STD810 certified with scrambler, flash memory and DB25 connector. This series of mobile radios is equipped also with standard and customized selective call, public address and data transmission (ETS300 - 113)

Frequency range: TX/RX: 136-174 MHz
Shipped today - Stock: 1
€229.95 (190.04 excl. 21% VAT)

Features

  • Emergency (SOS) function: Yes
  • Priority channel scan: Yes
  • High/low power selection: Yes
  • Operating Band: 38 MHz
  • Scrambler: Yes
  • CTCSS: Yes, standard tones
  • DCS: Yes, standard tones
  • Transponder: Yes, on selective call
  • Phone book: Yes
  • Remote use front panel: Yes
  • TOT (time out timer): Yes
  • Busy channels lockout: Yes
  • Squelch: Yes, adjustable
  • Program: Yes, by computer

Electrical data

  • Frequency step: 5 kHz / 6.25 kHz /
  • Channels: 250
  • Operating temperature: -25℃ to +55℃
  • Channel spacing: 25 KHz / 20 KHz / 12.5 KHz

Transmitter

  • Power output (Watts): UHF: 25/4 Watts (±1 dB)
  • Spurious Emissions: from 9 KHz to 1 GHz <-36 dBm / from 1 to 4 GHz <-30 dBm
  • Modulation System: FM (F3E) / PM (G3E)
  • Maximum Deviation: ± 2.5 (@ 12.5 KHz) / ±5 (@ 25 KHz)
  • Adjacent Channel Power Attenuation: < -60 dB (@ 12.5 KHz) / -70 dB (@ 20-25 KHz)

Receiver

  • Sensitivity (at 12 dB SINAD): <0.3 μV
  • Squelch Sensitivity (SINAD): <0.25 μV with 3 dB hysteresis
  • Spurious Response Rejection: >70 dB
  • Selectivity (Adjacent Channel): At least -60 dB (@ 12,5 KHz) / -70 dB (@ 25 KHz)
  • Intermodulation: >65 dB

Mechanical data

  • Length: 174 mm
  • Height: 48 mm
  • Width: 150 mm
  • Weight: 1400 gram
  • Antenna connector: PL 259 (UHF) female
  • Front speaker: Yes, 4 Watts

Inside the box

  • Transceiver: Yes
  • Microphone: Yes
  • Mounting bracket: Yes
  • DC cable: Yes
