Certified European Distributor

Albrecht - AE 6120 VOX

Product code: 12620
Factory code: 12620
Barcode: 4032661126207

AE 6120 VOX with integrated VOX hands-free function for easy communication. The Albrecht AE 6120 VOX is a miniature CB radio with all the essential functions you need on the road. The highlight: With a width of only 11 cm and a height of 2.5 cm, it is a true space miracle and can be installed everywhere without any problems. With its die-cast housing it is very stable and withstands strong external loads.

Frequency range: 26.965 - 27.405 MHz
Out of stock - Longer delivery time
€74.95 (61.94 excl. 21% VAT)

Features

  • Modulation: AM / FM
  • Multi-bands: Yes
  • Output power: 1-4 Watt
  • Channels: 40 AM / FM
  • Display type: LCD display
  • Display colors: Orange
  • VOX Function: Yes
  • Squelch: ASQ (Automatiq Squelch Systeem)
  • Emergency channel: Yes
  • Scan function: Yes
  • External speaker socket: Yes
  • S-meter: Yes
  • RF gain: Yes

Electrical data

  • Voltage: 13,8 Volt
  • Operating temperature: -20° to +55° C
  • Frequency control: PLL synthesizer

Transmitter

  • Audio frequency response: 300 Hz - 3 kHz
  • Frequency allowance: ± 300 Hz

Receiver

  • AM sensitivity: 1.0 µV for 10 dB SINAD
  • FM sensitivity: 1.0 µV for 20 dB SINAD
  • Frequency response: 300 Hz - 3 kHz
  • Adjacent channel selectivity: 60 dB
  • Maximum audio power: 1 Watt
  • Internal speaker: 8 Ohm, round

Mechanical data

  • Length: 102 mm
  • Height: 25 mm
  • Width: 111 mm
  • Weight: 300 gram
  • Antenna connector: UHF (PL) female (SO-239)
  • Mike connector: RJ45 connector

Inside the box

  • Transceiver: 1 pcs
  • Microphone: 1 pcs
  • Fixing screws: 1 set
  • Mounting bracket: 1 pcs
  • Power lead: 1 pcs
  • User Manual: English, German, Italian, French
