AnyTone - SM-0153 mike AnyTone - SM-0153 mike AnyTone - SM-0153 mike

AnyTone - SM-0153 mike

Product code: 30579

The AnyTone SM-0153 microphone is an original AnyTone microphone and is suitable for the AT-D578UV series.

Out of stock - Longer delivery time
€24.75 (24.75 excl. 0% VAT)

Features

  • Suitable for: AnyTone AT-D578UV
  • Up down: Yes
  • Lock button: Yes
  • A/B Sub PTT: Yes
  • A/B channel RX/TX indicator: Yes

Mechanical data

  • Microphone connector: RJ45

Microphone wiring

  • Receive: Pin 1
  • Transmit: Pin 3
  • Ground: Pin 8
  • 5V: Pin 2
  • SP +: Pin 4
  • SP -: Pin 7
  • MIC GND: Pin 5
  • MIC: Pin 6
