Intek - KT-900EE

Product code: 2600900

Barcode: 8032668403291

The Intek KT-900EE is a dual band transceiver suitable for 144-146 / 430-440 MHz. The KT-900EE will be delivered with a 1200 mAh Li-Ion battery pack.

Frequency range: TX/RX: 144-146 / 430-440 MHz, RX: 76-108 MHz (FM)

Note - Discontinued

€ -- (Discontinued)

Features

• Display: Yes
• TOT (time out timer): Yes
• FM radio: Yes,
• FM modulation: WFM

Electrical data

• Frequency step: 5 kHz / 6.25 kHz / 10 kHz / 12.5 kHz / 25 kHz / 50 kHz /
• Channels: 128
• Operating temperature: -20℃ to +55℃

Transmitter

• Power output (Watts): VHF: 5/1 Watts / UHF: 4/1 Watts
• Work mode: F2D / F3E
• Antenna impedance: 50 Ohm
• Frequency stability: ±2.5 PPM
• Max. deviation: ≤±5 KHz / ±2.5 KHz
• Spurious / harmonics: in compliance with the R&TTE regulations

Receiver

• Audio power output: ≤500 mW
• Sensitivity (12dB SINAD): 1.8 µV

Mechanical data

• Length: 58 mm
• Height: 95 mm
• Width: 40 mm
• Weight: 220 gram
• Antenna connector: SMA female

Inside the box

• Transceiver: Yes
• Battery: Li-Ion 1200 mAh
• Charger: Desk charger with adapter
• Antenna: Yes
• Installation manual: English and Italian
• Belt clip: Yes
• Hand strap: Yes
