mAT-tuner - mAT-1F

mAT-tuner - mAT-1F

Product code: 700702

The mAT-1F is an antenna tuner designed specifically for the Yaesu FTX-1 Field and cannot be used with other transmitters! It is fully compatible with the original brand's antenna tuner, allowing users to operate it directly from the transmitter's front panel just as they would with the original tuner.

The top panel features two antenna connectors: a BNC jack and banana terminals. These allow users to operate either a coax-fed antenna or a wire antenna, providing excellent flexibility and convenience.

The bottom panel also includes two connectors: the RF input jack and the control connector. The RF input jack connects to the transmitter's HF antenna jack through a coaxial feed line, while the control cable jack connects to the transmitter's "TUNER" connector using the supplied mAT-CF control cable.

Frequency range: 1.8 - 54.0 MHz
Out of stock - Longer delivery time
€139.95 (115.66 excl. 21% VAT)
Out of Stock

Features

  • Suitable for: Yaesu FTX-1 Field
  • Antenna connectors: BNC jack and banana terminals for coax-fed or wire antennas
  • Control interface: Full front-panel control compatibility with original tuner
  • RF input: Connects to transmitter's HF antenna connector via coaxial cable
  • Control connection: Uses supplied mAT-CF control cable to transmitter's "TUNER" connector
  • Operation: Direct control from transmitter's front panel
  • Memory channels: 16000
  • Antenna compatibility: Dipoles, verticals, Vees, beams, wire or any coax-fed antenna

Electrical data

  • Impedance: 5 - 1500 Ohm
  • Power range: 10 Watts
  • Tuning time: < 10 seconds (full tune)
  • Operating temperature: -10℃ ~ +60℃

Mechanical data

  • Input connector: BNC female
  • Output connector: BNC female
  • Length: 142 mm
  • Height: 67 mm
  • Width: 28 mm
  • Weight: 200 gram

Inside the box

  • Tuner: Yes
  • Installation manual: English
  • Control cable: 1x mAT-CF Control Cable (1 meter)
  • Coaxial cable: 1x mAT-CBB1M BNC Coaxial Cable (1 meter)
