Certified European Distributor

Polmar - Galaxy VHF

Product code: 7100055
Barcode: 8032182535294

The Polmar Galaxy VHF is a single band transceiver suitable for 144-146 MHz. The Galaxy VHF will be delivered with a 1200 mAh Li-Ion battery pack.

Frequency range: TX/RX: 144-146 MHz
Note - Discontinued
€ -- (Discontinued)

Features

  • Display: Yes, led backlight
  • VOX function: Yes
  • Emergency (SOS) function: Yes
  • High/low power selection: Yes
  • Voice guide: English
  • CTCSS codes: 48 groups
  • DCS codes: 83 groups
  • SQL function: Yes
  • Quick-charge: Yes, stop automatically when it's full
  • Auto scan function: Yes
  • Battery capacity: Li-ion1200 mAh

Electrical data

  • Channels: 99
  • Operating temperature: -10 °C to +55 °C

Transmitter

  • Power output (Watts): HI: 5 Watts ±1 dB LO: 1 Watts
  • Modulation: FM
  • Emission current: HI: ≤1.7A LO: ≤0.80A
  • Max. frequency deviation: ±5 KHz
  • Channel space: 25 KHz

Receiver

  • Audio distortion: ≤5%
  • Audio power output: ≤500 mW
  • Sensitivity (12dB SINAD): ≤0.20 µV
  • Squelch sensitivity: ≤0.16 µV
  • Inter modulation: 50 dB
  • Receiving current: ≤140 mA
  • Squelch waiting: Average 35 mA

Mechanical data

  • Length: 60 mm
  • Height: 125 mm
  • Width: 35 mm
  • Weight: 350 gram
  • Antenna connector: SMA male

Inside the box

  • Transceiver: Yes
  • Battery: Li-Ion 1200 mAh
  • Charger: Desk charger with adapter and 12 V car charger
  • Antenna: Yes
  • Installation manual: English
  • Belt clip: Yes
