Certified European Distributor

RM - KL300P

Product code: 1747
Barcode: 000000001328

The RM KL300P 'black line' is a linear amplifier with inversion polarity protection and antenna pre-amplifier. The max. output power off the amplifier is 150 Watts AM-FM and 300 Watts SSB (PEP).

Frequency range: 3-30 MHz
Shipped today - Stock: 8
€246.95 (204.09 excl. 21% VAT)

Electrical data

  • Input power (Watts): 1-5 AM-FM / 2-10 SSB-CW
  • Max output power (Watts): 140 AM-FM
  • Max output power SSB (Watts): 250 (PEP)
  • Impedance: 50 Ohm
  • Max input SWR: 1.1 - 1.5
  • Fuse: 2x 12 A
  • Inversion polarity protection: Yes
  • Electronic switch: Yes
  • Pre-amplifier: Yes
  • Output power level: 2
  • Input energy/power: 14-20 A
  • Antenna pre-amplifier: 26 dB

Mechanical data

  • Input connector: UHF (PL) female
  • Output connector: UHF (PL) female
  • Length: 109 mm
  • Height: 35 mm
  • Width: 225 mm
  • Weight: 605 gram
  • Color: Black

Inside the box

  • Amplifier: Yes
  • Installation manual: English
