Sirio - SCO-1.09-5

Product code: 213222000

Factory code: 2132220.00

Barcode: 8056182115850

The Sirio SCO-1.09-5 is a base antenna that can be used for 1090 MHz ADS-B flight data reception systems. Strong 555 mm fiberglass tube with an aluminium bracket for an easy installation on the mast. N-female, gold plated central pin, connector.

Frequency range: 1090 MHz (ADS-B system)

Out of stock - Longer delivery time

€49.95 (41.28 excl. 21% VAT)

Electrical data

• Electrical type: 3×1/2 λ colinear
• Gain: 2.65 dBd - 4.8 dBi
• Impedance: 50 Ohm
• Polarization: Linear vertical

Mechanical data

• Materials: Fiberglass, Chromed Brass, Nikel plated brass, PCB, Aluminium, Stainless stee
• Mast Ø: 35 - 54 mm
• Max wind resistance: 150 km/h
• Height: 555 mm
• Weight: 288 gram (without bracket)
• Mounting type: On mast, On wall
• Antenna connector: N-female, gold plated central pin
• Operating temperature: -40 °C to +80 °C

Inside the box

• Antenna: Yes
• Mounting parts: Yes
• Installation manual: English

Downloads

• Datasheet: SCO 1 09 5
