Stabo - XM 3002E Stabo - XM 3002E

Stabo - XM 3002E

Product code: 30128
Factory code: 30128
Barcode: 4010384301286

The Stabo XM-3002E is a compact multi-norm CB radio, with a very short body (only 85.5 mm deep), for professional use in cars, vans, and trucks. It's DIN-size design with and 12/24V operation makes it easy to fit in any standard car radio slot.

The XM-3002E features a clear LCD multifunction display with channel and frequency indication, including 7 selectable background colors for improved visibility. With 6 switchable frequency bands, programmable memory channels, scan function, and direct access to priority channels 09/19, this radio is designed for reliable and efficient communication on the road.

For improved operating comfort, the Stabo XM-3002E includes VOX hands-free operation, manual squelch and ASC automatic noise suppression, plus ANL and NB filters for reduced interference. Additional functions such as Roger Beep, mute, Time-out Timer, and external speaker and microphone connections complete this versatile CB mobile radio.

You can find all the technical details in the user manual available in the 'Downloads' section at the bottom of this product page.

Frequency range: 26.965 - 27.405 MHz
Out of stock - Longer delivery time
Available from - 27-05-2026
€209.95 (173.51 excl. 21% VAT)

Features

  • Modulation: AM / FM
  • Multi-bands: Yes
  • Output power: 4 Watt
  • Channels: 40 AM / FM
  • Front speaker: Yes
  • Display type: LCD display
  • Display colors: 7 colors
  • VOX Function: Yes
  • Noise blanker: Yes
  • Squelch: ASQ (Automatiq Squelch Systeem) / Manual squelch /
  • Emergency channel: Yes
  • Scan function: Yes
  • Memory channels: Yes
  • External speaker socket: Yes
  • External PA socket: Yes
  • S-meter: Yes
  • RF gain: Yes
  • TOT (time out timer): Yes
  • Din mount: Yes
  • Roger Beep: Yes

Electrical data

  • Voltage: 13,8 Volt / 24 Volt /

Transmitter

  • Audio frequency response: 300 Hz - 3 kHz
  • Microphone sensitivity: 3,0 mV
  • Transmission interference: Better than -54 dBm (4 nW)
  • Adjacent channel interference: > 20 μW
  • Frequency allowance: ± 200 Hz
  • Drain: 13.2 Volt: 2.5A, 26.4 Volt: 1.3A

Receiver

  • AM sensitivity: 0,79 μV (-109 dBm)
  • FM sensitivity: 0,39 μV (-115 dBm)
  • Frequency response: 300 Hz - 3 kHz
  • Adjacent channel selectivity: 60 dB
  • Squelch sensitivity: Min. 0,2 μV (-120 dBm) / Max. 1,0 mV (-47 dBm)
  • IF rejection: 70 dB
  • Intermodulation suppression: 60 dB
  • Drain: 13.2 Volt: 160 - 500 mA, 26.4 Volt: 90 - 300 mA

Mechanical data

  • Length: 85.5 mm
  • Height: 50
  • Width: 658 mm
  • Weight: 1066 gram
  • Antenna connector: UHF (PL) female (SO-239)
  • Mike connector: 6 pin connector

Inside the box

  • Transceiver: 1 pcs
  • Microphone: 1 pcs
  • Fixing screws: 1 set
  • Mounting bracket: 1 pcs
  • Power lead: 1 pcs
  • DIN mount: 1 pcs
  • User manual: Yes

Downloads
