Zetagi - R20

Product code: 16

The Zetagi R20 is a voltage reducer from 18-30V to 13.8V DC power. The reducers is ideal for powering smaller devices such as CB radios, small TV's, etc. It has full protection against short circuit, over load and over-temperature. Continuous output 10A and a peak of 20A and connection is via screwterminals (no cable included).

Note - Price on request

€ -- (Price on request)

Electrical data

• Input power: 18-30 Volt
• Output voltage: 13.8 Volt
• Continuous output current: 10 A
• Maximum peak current: 20 A

Mechanical data

• Length: 200 mm
• Height: 63 mm
• Width: 120 mm
• Weight: 1300 gram

Inside the box

• Voltage reducer: Yes
• User manual: English
