Comet - CMX-200 Comet - CMX-200 Comet - CMX-200 Comet - CMX-200 Comet - CMX-200

Comet - CMX-200

Product code: 805200
Barcode: 4932273180829

The Comet CMX-200 is a high quality cross needle meter that can be used for 1.6 - 200 MHz, to measure Forward Power, Reflected Power and SWR. With a maximum PEP power handling of 3 kW on HF and 1 kW on VHF. PEP switch to select average power or SSB / PEP. The Comet CMX-200 has a large and illuminated display. Gold-plated inner core connectors.

Frequency range: 1.6 - 200 MHz
Out of stock - Longer delivery time
€158.95 (131.36 excl. 21% VAT)

Electrical data

  • Backlight display / meter: Yes
  • Impedance: 50 Ohm
  • Power range: 1.8 - 30 MHz: 30 / 300 / 3000 Watts, above 50 MHz: 30 / 300 / 1000 Watts
  • Accuracy: ±10%
  • Minimum Power for SWR: 6 Watts
  • Insertion loss: 0.2 dB
  • Testing function: SWR and Power (FWD and REF / AVG and PEP)
  • Voltage: 13.8 Volt, for display lightning only
  • Maximum continuous power handling 1.8 - 30 MHz: 2 kW
  • Maximum continuous power handling above 50 MHz: 800 Watts

Mechanical data

  • Input connector: UHF (PL) female, gold-plated inner core
  • Output connector: UHF (PL) female, gold-plated inner core
  • Length: 120 mm
  • Height: 80 mm
  • Width: 105 mm
  • Weight: 623 gram

Inside the box

  • Meter: Yes
  • DC power cable: Yes
  • Installation manual: English
