Grazioli - FE62V

Product code: 8020020

Factory code: 8020020

The Grazioli FE62V is a vertical 2x5/8 λ collinear VHF antenna, tunable from 50 to 54 MHz using the included tuning table. The antenna can also be configured in a shorter 5/8 λ version, with a dedicated whip length adjustment chart. It features an extremely robust construction made from AW6063-T66 aluminum alloy, ensuring durability in demanding environments. All fasteners are made from high-grade 304 and 316 stainless steel, providing long-term corrosion resistance for a rust-free service life. The ground plane is composed of four full quarter-wave radials, ensuring stable performance. Capable of handling high input power—up to 2 kW continuous in all operating modes. Each unit comes with a detailed assembly manual and a unique serial number for production batch and build data identification.

For full product details, please refer to the user manual:

Frequency range: 50.0 - 54.0 MHz tunable

Shipped next business day - Stock: 2

€269.95 (223.1 excl. 21% VAT)

Electrical data

• Electrical type: 2x 5/8 λ Collinear Ground Plane with four radial
• Gain: 1.50 dBd - 3.65 dBi
• VSWR: ≤1.2:1
• Bandwidth: ≥ 3.1 MHz at 50 MHz
• Maximum continuous power: 2000 Watts (CW)
• Impedance: 50 Ohm
• Polarization: Linear vertical
• Feed system: High “Q” air wound matching coil, DC-Ground

Mechanical data

• Materials: Aluminnum Alloy AW6063-T66 hard drawn tube, Fiberglass, Brass, PTFE. All hardware are made of SS AISI-304 and 316
• Mast Ø: 40 - 54 mm
• Max wind resistance: 130 km/h
• Length: 812 cm
• Height: 4170 mm (including bracket)
• Weight: 4300 gram
• Mounting type: On mast
• Antenna connector: UHF-female, PTFE insulator & gold plated central pin
• Radial length: 1400 mm

Inside the box

• Antenna: Yes
• Mounting parts: Yes
• Installation manual: English, Italian

Downloads

• Datasheet: Grazioli FE62 V MANUAL UK
