K-PO - DMC 520 P4

Product code: 910022

The K-PO DMC 520 P4 is a nice solid and high quality microphone. This is an universal microphone and is suitable for most 4 pin CB radios that have the old President / Uniden 4-pin wiring.

Note - Discontinued
€ -- (Discontinued)

Features

  • Suitable for: 4-pin P4 connector
  • Dynamic microphone: Dynamic microphone

Electrical data

  • Frequency response: 200-5000 Hz
  • Impedance: 500 Ohm
  • Sensitivity: -76 dB (0 dB=1 V/u bar)

Mechanical data

  • Cable Length: 2.20 m

Microphone wiring

  • Receive: Pin 4
  • Transmit: Pin 3
  • Mic Audio: Pin 2
  • Ground: Pin 1
