Midland - HP 406

Product code: 933

Ideal for public and private sector surveillance, HP06 provides a highly valuable contribution to service delivery in surveillance or security fields, using practical and personalized solutions which respond to any and all communications requirements, from the most simple to the most complex.
Thanks to the multiple call functions, the user can also program group or emergency call sequences on predefined channels, block busy channels (Busy Lockout), and set start and end conversation times, optimizing the use of radio channels. The inbuilt scrambler allows for the encoding of calls while still remaining transparent to the user, ensuring maximum privacy during conversations. The Lone Worker function, available as an option; is ideal to protect the users working in remote or isolated areas, thanks to the sending of special emergency codes.

Frequency range: TX/RX: 400-470 MHz
Shipped next business day
€74.34 (74.34 excl. 0% VAT)

Features

Electrical data

  • Frequency step: 5 kHz / 6.25 kHz /
  • Channels: 16
  • Channel spacing: 12.5 kHz (narrow band) / 20 kHz / 25 kHz (wide band) /
  • Operating Voltage: 7,4 volt
  • Operating temperature: –30 to +60

Transmitter

  • Power output: 1W Low / 5W Hi
  • Modulation limit: ±2,5/5 KHz
  • Spurious emission transmitter: From 9KHz to 1GHz <0,25 from 1 to 4GHz
  • Audio distortion transmitter: 5% or less

Receiver

  • Sensitivity: <0.35 μV
  • Hum & noise: <-45 to <-40 dB
  • Audio power output: 400 Mw

Inside the box

  • Transceiver: Yes
  • Battery: No battery supplied
  • Antenna: Yes
  • Installation manual: English
