Midland - K-PO 98 E

Product code: 100098
Factory code: 100098
Barcode: 8011869127113

The K-PO Midland 98 Plus is a compact radio that really punches above its weight. In spite of being one of the most affordable radios it incorporates high standards of build quality and technology that add up to make it a very attractive little CB.

Frequency range: 26.965 - 27.405 MHz
Shipped next business day
€61.94 (61.94 excl. 0% VAT)

Features

  • Modulation: FM
  • Output power: 4 Watt
  • Channels: 40 FM
  • Display type: Backlight
  • Display colors: Orange
  • Squelch: Manual squelch
  • Emergency channel: Yes
  • External speaker socket: Yes
  • External S-meter socket: Yes
  • S-meter: Yes

Electrical data

  • Voltage: 13,8 Volt
  • Frequency control: Precision PLL synthesizer

Transmitter

  • Audio frequency response: 300 Hz - 3 kHz
  • Modulation FM: 1.8 kHz to ± 0.2 kHz

Receiver

  • Frequency response: 300 Hz - 3.0 kHz
  • Adjacent channel selectivity: 65 dB
  • Sensitivity with ESP: 0.3 μV for 20 dB SINAD
  • Sensitivity without ESP: 0.7 μV for 20 dB SINAD
  • Receiving system: Dual conversion superheterodyne
  • IF frequencies: Double conversion 1st 10.695 MHz / 2nd 455 kHz
  • Audio distortion: Less than 8% @ 1 kHz

Mechanical data

  • Length: 120 mm
  • Height: 40 mm
  • Width: 190 mm
  • Weight: 737 gram
  • Antenna connector: UHF (PL) female (SO-239)
  • Mike connector: 6 pin connector

Inside the box

  • Transceiver: 1 pcs
  • Microphone: 1 pcs
  • Fixing screws: 1 set
  • Mounting bracket: 1 pcs
  • User Manual: English
