RigExpert - MATCH + Advance license

Product code: 13019

Black Friday deal in cooperation with RigExpert: 50% discount on the Advance license, valid only for end users, and for purchases between November 27th and December 3rd, 2025.

Package deal: including ADVANCE license: Extends coverage to 0.1–230 MHz and adds extra features.

The new, upgradeable Antenna and Cable Analyzer, MATCH, is set to revolutionize the field, featuring cutting-edge technology designed to grow with your needs.

MATCH is the perfect tool for hobbyists and professionals alike to analyze and fine-tune antennas and cables with precision. User-friendly, versatile, and future-ready, MATCH empowers you to “Grow Your Game.”

For a detailed comparison between the BASE model, the ADVANCED and RFE licenses, refer to the comparison table available in the "Downloads" section at the bottom of this product page.

Product video (YouTube): MATCH

Frequency range: 0.1 - 230 MHz
Out of stock - Longer delivery time
Available from - 27-11-2025
€359.95 (297.48 excl. 21% VAT) - €399.95

Features

  • Frequency range Base model: 0.1 to 75 MHz
  • Memory Slots for saving measurements: Yes
  • Jump to Extremum Value: Yes
  • Save Measurements: Yes
  • Load Measurements: Yes
  • Choosing GUI Language: Yes
  • Chosing GUI Palette: Yes
  • Choosing Battery Profile: Yes
  • Controlling Sound: Yes
  • Selecting System Impedance: Yes
  • Chosing Metric/Imperial Units: Yes
  • Choosing IARU Regions: Yes
  • Setting the Cable Velocity Factor: Yes
  • Setting Frequency Correction Factor: Yes
  • Factory Reset: Yes
  • Clearing Saved Charts: Yes
  • Table modes: R, X, Z, L, C, Loss, Phase Meter
  • Display modes: SWR Chart / RX Chart / Return Loss Chart
  • Languages: English / Ukrainian / Spanish / French / German / Portuguese / Italian
  • Tools:: Self test

Mechanical data

  • Output connector: N female connector
  • Length: 207 mm
  • Height: 37 mm
  • Width: 93 mm
  • Weight: 341 gram
  • Display: 480x480 color TFT 4.0” LCD display

Electrical data

  • Testing function: Yes Self-test
  • Output power: -10 dBm (at 50 Ohm load)
  • Operating temperature: -10…60 °C (14…140 °F)
  • Battery: Li-Ion battery ICR18650, 2600mAh

Inside the box

  • Analyzer: Yes
  • Programming and charging cable: Yes
  • Carrying case: Yes
  • Installation manual: English
