RM - BLA350V Plus

Product code: 50200022
Barcode: 5060080572748

Our stock is new and always the most recent version, V1.13. This version can be used on the 11 meter band without any modification.

The RM BLA350V Plus 'black line' is a HF broadband linear amplifier. The max. output power off the amplifier is 250-300 Watts AM-FM and SSB (PEP) and is equipped with 1 cooling fan.

The amplifier is easy to use without setup, instantaneous band change and no tuning required. Pay attention the amplifier has no pre-heating, protection against high ROS. The amplifier has a quiet forced variable speed cooling system and bandwidth, operating error indication. Separate selector for automatic or manual operation and low distortion and linear amplification. Using two MosFets SD 2941-10. Operates from 50 Volts for efficient, low distortion and linear RF power service.

Protection circuits are not 100% guaranteed. To prevent damage to your amplifier always check your VSWR after changing bands, no hot switching, no excessive input power etc.

Frequency range: 1.5-30 Mhz
Shipped next business day - Stock: 4
€1,299.95 (1074.34 excl. 21% VAT)

Electrical data

  • Input power (Watts): 1-14
  • Max output power (Watts): 250-300
  • Max output power SSB (Watts): 250-300
  • Impedance: 50 Ohm
  • Fuse: 4 A
  • Inversion polarity protection: Yes
  • Electronic switch: Yes
  • LCD display: Yes
  • Seperate LED displays for power and antenna VSWR: Yes
  • Cooling fans: 1
  • Output power level: 2

Mechanical data

  • Input connector: UHF (PL) female
  • Output connector: UHF (PL) female
  • Length: 270 mm
  • Height: 155 mm
  • Width: 355 mm
  • Weight: 13.000 gram

Inside the box

  • Amplifier: Yes
  • Installation manual: English
