RM - KL300 24V

Product code: 1749

The RM KL300/24 is a linear amplifier with inversion polarity protection is suitable for 24 Volt. The max. output power off the amplifier is 150 Watts AM-FM and 300 Watts SSB (PEP).

Frequency range: 25-30 MHz
Shipped next business day
€123.93 (123.93 excl. 0% VAT)

Electrical data

  • Input power (Watts): 1-8 / 2-16 SSB-CW
  • Max output power (Watts): 150 AM-FM
  • Max output power SSB (Watts): 300 (PEP)
  • Impedance: 50 Ohm
  • Max input SWR: 1.1 - 1.5
  • Fuse: 8 A
  • Inversion polarity protection: Yes
  • Electronic switch: Yes
  • Cooling fans: 2
  • Output power level: 2
  • Input energy/power: 14-20 A

Mechanical data

  • Input connector: UHF (PL) female
  • Output connector: UHF (PL) female
  • Length: 109 mm
  • Height: 35 mm
  • Width: 225 mm
  • Weight: 605 gram
  • Color: Red or Blue
