Yaesu - FTM-3100E

Product code: XAH052N308-0E
Factory code: XAH052N308-0E
Barcode: 4909959156331

Yaesu Promotion: Free Original Yaesu 2024 Gold/Black Cap. Available to end-users only.

The new Yaesu FTM-3100E is a ruggedly built yet compact VHF-FM mobile transceiver, providing highoutput power of up to 65 Watts to ensure stable long-distance communications. One of the distinguishing features of this exciting newmobile transceiver is the Front Panel Speaker delivering 3 Watts of loud and crystal clear audio; designed for stress-free and enjoyable communications - even in noisy environments.

This new mobile is equipped with a heavy-duty heat sink that includes an extraordinary FACC; Funnel Air-Convection Conductor (Wind Tunnel). The FACC gathers cool air through a wide open front air-intake and concentrates the air flow to the critical final amplifier area drawn by a rear cooling fan.

Powerful and Rugged 65 Watt Transmitter

Enjoy 65 Watts of 2-Meter RF Output to ensure long distance communication even in the toughest of situations. Type: F3E Variable Reactance Modulation.

3 watts of crystal clear front panel audio

In any environment enjoy loud and crystal clear audio with 3 Watts of audio from the FTM-3200R's front mounted speaker. 8 Watt output using Optional External Speaker (MLS-200-M10)

FACC - Funnel Air-Convection Conductor (Wind Tunnel).

Cool air is drawn through a wide open front air intake and is then concentrated over critical areas of the Power Amplifier (PA) section of the FTM-3100E.

Frequency range: TX: 144-146 / RX: 136-174 MHz
Shipped next business day
€149.94 (123.92 excl. 21% VAT)

Features

  • Display: Yes with backlight
  • DTMF: Yes
  • Mode of emission: F3E
  • CTCSS/DCS: Yes
  • Enhanced Paging & Code Squelch (EPCS): Yes, Use the pager code consisting of two CTCSS tones to exchange communications with specified stations
  • Split Tone Operation: Yes, The FTM-3100E can be operated in a “Split Tone” configuration that enables operation on repeaters using a mix of both CTCSS and DCS control via the Setup menu
  • Clone: Yes, The FTM-3100E includes a convenient “Clone” feature, which allows the memory and configuration data from one transceiver to be transferred to another FTM-3100E
  • Band Edge Beeper: Yes, the FTM-3100E will automatically “beep” when the receiver’s band edge is encountered during scanning (either in standard VFO scanning or during PMS operation).
  • Automatic Power-Off (APO): Yes, The “Automatic Power-Off” (APO) feature will turn the radio completely off after a userdefined period of PTT or key/button inactivity.
  • Busy Channel Lock-Out (BCLO): Yes, The BCLO feature prevents the radio’s transmitter from being activated if a signal strong enough to break through the “noise” squelch is present.
  • MIC Gain: Yes, At the factory, a microphone gain has been programmed that should be satisfactory for the supplied MH-48 A6J Microphone.
  • PAGER (EPCS): Yes, This feature allows calling specified stations only, by using a pager code that combines two CTCSS tones.
  • Time-out Timer: Yes
  • External speaker socket: Yes

Electrical data

  • Frequency step: 5 kHz / 6.25 kHz / 10 kHz / 12.5 kHz / 15 kHz / 20 kHz / 25 kHz / 50 kHz / 100 kHz /
  • Wide and narrow bandwidth selection: Yes
  • Operating temperature: -20℃ to +60℃
  • Frequency stability: ±10 PPM
  • Operating voltage: 13.8 Volt (Negative Ground) ±15%
  • Current consumption: RX: less than 0.7 A, less than 0.5 A (squelched) / TX: 15 A (65W) / 10 A (30W) / 5 A (5W)
  • Standard repeater shift: ±600 kHz

Transmitter

  • Power output (Watts): 5/30/65 Watts
  • Spurious Emission: ≤ 61.1 dB
  • Modulation type: F3E: Variable Reactance Modulation
  • Maximum deviation: Wide: ±5 kHz / Narrow: ±2.5 kHz
  • Antenna impedance: 50 Ω
  • Microphone impedance: 2k Ω

Receiver

  • Sensitivity (wide): 0.20 μV for 12 dB SINAD
  • Sensitivity (narrow): 0.22 μV for 12 dB SINAD
  • Intermediate frequency 1st: 47.25 MHz
  • Intermediate frequency 2nd: 450 kHz
  • Receiving system: Dual conversion superheterodyne
  • Audio power output: 3W (THD10%, 13.8 V)
  • Selectivity (-6 dB/-60 dB) NFM/AM:: 12 / 28 kHz

Mechanical data

  • Length: 155 mm
  • Height: 43 mm
  • Width: 154 mm
  • Weight: 1300 gram
  • Antenna connector: UHF (PL) female (SO-239)
  • Microphone connector: RJ12

Inside the box

  • Transceiver: Yes
  • DC power cable: Yes
  • Installation manual: English
  • Microphone: Yes, MH-48A6JA DTMF Microphone
  • Mounting bracket: Yes
  • USB Cable: Yes
  • Fuse: Yes, Spare fuse (25A)
