Yaesu - SCU-17 USB interface

Product code: AAK21X001

Factory code: AAK21X001

Barcode: 4909959138061

The Yaesu SCU-17 USB interface unit may be used for CAT control of the transceiver with a computer via a USB connection and for communications using SSTV, RTTY and PSK digital modes. (Note: Yaesu does not produce CAT, SSTV, RTTY or PSK operating software).

Provides CAT communications through USB when PC does not have RS-232C port.
Has a USB audio system so the TX and RX audio is accessible through the USB cable.
Has a two-channel USB serial device and enables various transmit modes and CAT comms. simultaneously.
Operates from USB bus power, so no external power supply required.
Provides high RF isolation via photo relays.
Front panel TX and RX audio controls.
LED indicators monitor PTT and FSK control.

Out of stock - Longer delivery time

€129.95 (107.4 excl. 21% VAT)

Electrical data

Voltage: 5.0 V ±5%, (Negative Ground)
Consumption: 130 mA
Data jack: PTT: Maximum output +25 V, 50 mA / FSK: Maximum output +25 V, 50 mA / DATA-IN: 100 mVrms @ 10 k Ohm / DATA-IN: 100 mVrms @ 600 Ohm
FSK/PTT jack: PTT: Maximum output +30 V, 250 mA (open drain) / FSK: Maximum output +30 V, 250 mA (open drain)
Audio jack: AUDIO-IN: 100 mVrms @ 600 Ohm / AUDIO-OUT: 100 mVrms @ 600 Ohm
CAT/RS-232 jack: RS-232C voltage level
USB Connector: USB 1.1 or USB 2.0, USB bus power
