Albrecht - AE 6110 VOX

Product code: 12613
Factory code: 12613
Barcode: 4032661126115

Now with standard DC power cord and an extra DC power cord with cigarette lighter plug.

The Albrecht AE 6110 VOX CB Radio is so incredibly small that it will fit almost anywhere, it is just over 100 mm wide and deep, and only 25 mm thick.

Despite its small size, it has all the features you would expect from a modern entry level CB radio, including AM/FM multi-channel operation, auto-squelch, 6 segment LCD S-Meter, RF gain and scan functions. The AE 6110 VOX also comes complete with a fixed up and down microphone. Albrecht AE-6110, the tiny CB that makes a big impression.

Frequency range: 26.965 - 27.405 MHz
Out of stock - Longer delivery time
€74.95 (61.94 excl. 21% VAT)

Features

  • Modulation: AM / FM
  • Multi-bands: Yes
  • Output power: 4 Watt
  • Channels: 40 AM / FM
  • Display type: LCD display
  • Display colors: Orange
  • VOX Function: Yes
  • Squelch: ASQ (Automatiq Squelch Systeem) / Manual squelch /
  • Emergency channel: Yes
  • Keypad lock: Yes
  • Scan function: Yes
  • External speaker socket: Yes
  • S-meter: Yes
  • RF gain: Yes

Electrical data

  • Voltage: 13,8 Volt
  • Operating temperature: -20° to +55° C
  • Frequency control: PLL synthesizer

Transmitter

  • Frequency allowance: ± 300 Hz
  • Modulation AM: from 85% to 90%
  • Modulation FM: 1.9 kHz
  • Drain: 13.2 Volt: 2.0 A

Receiver

  • AM sensitivity: 1.0 µV for 10 dB SINAD
  • FM sensitivity: 1.0 µV for 20 dB SINAD
  • Frequency response: 300 Hz - 3 kHz
  • Adjacent channel selectivity: 60 dB
  • Maximum audio power: 1 Watt
  • Internal speaker: 8 Ohm, round
  • Image rejection: 70 dB

Mechanical data

  • Length: 100 mm
  • Height: 25 mm
  • Width: 102 mm
  • Weight: 450 gram
  • Antenna connector: UHF (PL) female (SO-239)
  • Mike connector: RJ45 connector

Inside the box

  • Transceiver: 1 pcs
  • Microphone: 1 pcs
  • Mounting bracket: 1 pcs
  • Power lead: 2 pcs
  • User Manual: English, German, Spanish, Italian, French, Polish, Romania
