Alinco - DJ-VX41E

Product code: 3381

The Alinco DJ-VX41E is a professional and PC programmable UHF, 400-470 MHz, handheld radio. With the optional programming software you can program up to 128 channels, 8 groups of 16 channels each, 0.5W, 2W or 5W output power, (de)activate VOX, program Voice Encryption and many other features. IP67 index, 30 minutes waterproof at 1 meter depth. Ergonomically designed and compact radio body.

Frequency range: TX/RX: 400-470 MHz
Shipped next business day
€148.72 (148.72 excl. 0% VAT)

Features

  • VOX function: Yes
  • DTMF: Yes, encode and decode
  • 2TONE/5TONE: Yes, encode and decode
  • Emergency (SOS) function: Yes
  • High/low power selection: Yes
  • Voice guide: English
  • CTCSS: Yes, encode and decode
  • DCS: Yes, encode and decode
  • Analog scrambling: Yes
  • Voice compander: Yes
  • Time-Out-Timer (TOT): Yes
  • Program: Yes, by computer

Electrical data

  • Frequency step: 2.5 kHz / 6.25 kHz /
  • Channels: 128
  • Channel spacing: 12.5 kHz (narrow band) / 25 kHz (wide band) /
  • Phase-locked Step: 2.5 kHz / 6.25 kHz
  • Operating Voltage: 7,4 Volt
  • Operating temperature: -20℃ to +60℃
  • Wide and narrow bandwidth selection: Yes

Transmitter

  • Power output: 0.5/2/4 Watts
  • Modulation limit: 16K0F3E / 11K0F3E
  • Adjacent channel power: Wide: ≥ 65 dB / Narrow: ≥ 60 dB
  • Audio distortion transmitter: ≤ 3%
  • Hum & noise: Wide: ≥ 40 dB / Narrow: ≥ 35 dB

Receiver

  • Sensitivity: Wide: ≤0.25 μV / Narrow: ≤0.25 μV
  • Spurious rejection receiver: Wide: ≥ 70 dB / Narrow: ≥ 70 dB
  • Hum & noise: Wide: ≥ 45 dB / Narrow: ≥ 35 dB
  • Audio power output: 1000 mW / 10%
  • Adjacent channel selectivity: Wide: ≥ 60 dB / Narrow: ≥ 60 dB
  • Intermodulation: Wide: ≥ 55 dB / Narrow: ≥ 55 dB

Mechanical data

  • Length: 38 mm
  • Height: 118 mm
  • Width: 59 mm
  • Weight: 230 gram
  • Antenna connector: SMA
  • Waterproof: IP67
  • Accessory connector: 2 pin Standard Icom (S)

Inside the box

  • Transceiver: Yes
  • Battery: 1800 mAh Li-ion battery pack (EBP-101)
  • Charger: Desk charger with AC adapter (EDC-221 - EDC-219)
  • Antenna: Yes
  • Installation manual: English
  • Belt clip: Yes, EBC-51
