CRT - Alpha

Product code: 600190
Factory code: TX 000190
Barcode: 3140650006377

The CRT Alpha is a brand new CB radio from CRT with large 7 colours LCD display. The Alpha is easy to operate and has the most essential functions and suitable for 12 and 24 Volt. The CB radio is supplied complete including a mounting set and cigarette lighter adapter.

Frequency range: 26.965 - 27.405 MHz
Shipped today
€66.07 (66.07 excl. 0% VAT)

Features

  • Modulation: AM / FM
  • Multi-bands: Yes
  • Output power: 4 Watt
  • Channels: 40 AM / FM
  • Display type: LCD display
  • Display colors: Green / Orange / Purple / Blue / Cyaan / Yellow / Clear Blue
  • VOX Function: Yes
  • Noise blanker: Yes
  • Squelch: ASQ (Automatiq Squelch Systeem) / Manual squelch /
  • Emergency channel: Yes
  • Keypad lock: Yes
  • Scan function: Yes
  • External speaker socket: Yes
  • S-meter: Yes
  • RF gain: Yes
  • Car socket connector: Yes
  • Roger Beep: Yes
  • CTCSS: Yes 38, decode and encode
  • DCS: Yes 104, digital and analog code to activate

Electrical data

  • Voltage: 13,8 Volt / 24 Volt /
  • Operating temperature: -20° to +55° C
  • Frequency tolerance: ± 5.0 ppm

Transmitter

  • Audio frequency response: 300 Hz - 3 kHz
  • Impedance: 50 Ohm
  • Drain: 13.8 Volt: 3.0 A max.

Receiver

  • AM sensitivity: Less than 1.0 µV for 10 dB
  • FM sensitivity: Less than 1.0 µV for 10 dB
  • Frequency response: 300 Hz - 3 kHz
  • Adjacent channel selectivity: 60 dB
  • Maximum audio power: 2 Watt
  • Internal speaker: 8 Ohm, round
  • Image rejection: 70 dB
  • IF frequencies: Double conversion 1st 10.695 MHz / 2nd 455 kHz
  • Squelch: Less than 1 µV,
  • Automatic Gain Control (AGC): Less than 10 dB change in audio, output for inputs from 10 to 50000 uV

Mechanical data

  • Length: 185 mm
  • Height: 38 mm
  • Width: 124 mm
  • Weight: 620 gram
  • Antenna connector: UHF (PL) female (SO-239)
  • Mike connector: 6 pin connector

Inside the box

  • Transceiver: 1 pcs
  • Microphone: 1 pcs
  • Fixing screws: 1 set
  • Mounting bracket: 1 pcs
  • Power lead: 1 pcs
  • User Manual: English, French
  • Fuse: 1 pcs
