Astatic - AST36ST

Product code: 1040
Barcode: 631922103267

The Dial-A-Match series have a unique design which allows field tuning and mounting in any configuration with a simple twist of the tuning collar. Re-tuning is made easy by simply adjusting the split collar to the same SWR. Metal parts are either 17-7 PH stainless stell or triple chrome-plated brass for long lasting service and beauty.

The Astatic AST36ST comes with a 36 inch (91 cm) stainless steel whip, heavy duty double groove aluminium mirror mount and a 3.65 meter RG 58 cable with PL-259 connectors.

Frequency range: 26.9 - 27.4 MHz
Note - Discontinued
€ -- (Discontinued)

Electrical data

  • Electrical type: Base loaded
  • Power peak: 50 Watts
  • Impedance: 50 Ohm
  • Polarization: Linear vertical
  • Cable: Yes
  • Cable length: 3.65 meter / RG 58

Mechanical data

  • Materials: 17-7 PH stainless steel, aluminium, chromed brass, plastics
  • Height: 1000 mm
  • Mounting type: Mirror mount

Inside the box

  • Antenna: Yes
  • Radio connector: UHF-male (PL)
  • Mounting parts: Yes
  • Antenna cable: Yes
  • Installation manual: English, French
