CRT - S8040

Product code: 600180
Factory code: TX 000180
Barcode: 3140650006490

Refurbished item, one time used.

The CRT S8040 is a multi standard CB radio and is one of the simplest entry models on the market. The S8040 is easy to operate and has the most essential functions such as AM / FM, Scan and an Up & Down microfoon. The CB radio is supplied complete including a mounting set.

Frequency range: 26.565 - 27.405 MHz
Shipped next business day
€34.68 (34.68 excl. 0% VAT) - €49.54

Features

  • Modulation: AM / FM
  • Multi-bands: Yes
  • Output power: 4 Watt
  • Channels: 40 AM / FM
  • Display type: Backlight
  • Display colors: Orange
  • Squelch: ASQ (Automatiq Squelch Systeem) / Manual squelch /
  • Emergency channel: Yes
  • Scan function: Yes
  • External speaker socket: Yes
  • Roger Beep: Yes

Electrical data

  • Voltage: 13,8 Volt
  • Operating temperature: -10° to +55° C
  • Frequency tolerance: 0.005 %

Transmitter

  • Audio frequency response: 300 Hz - 3 kHz
  • Harmonic suppression: Less than -54 dBm
  • Drain: 13.8 Volt: 3.0 A max.

Receiver

  • AM sensitivity: 1.0 µV for 10 dB
  • FM sensitivity: 1.0 µV for 10 dB
  • Frequency response: 300 Hz - 3 kHz
  • Maximum audio power: 3 Watt
  • Squelch: Minimum 0.2 µV -120 dBm / maximum 1 µV

Mechanical data

  • Length: 150 mm
  • Height: 41 mm
  • Width: 140 mm
  • Weight: 761 gram
  • Antenna connector: UHF (PL) female (SO-239)
  • Mike connector: 6 pin connector

Inside the box

  • Transceiver: 1 pcs
  • Microphone: 1 pcs
  • Fixing screws: 1 set
  • Mounting bracket: 1 pcs
  • Power lead: 1 pcs
  • User Manual: English, German, French
