Deshibo - WV-601
The Deshibo WV-601 is an innovative portable passive loop antenna designed for wideband signal reception from 0 to 999 MHz, covering longwave, medium wave, shortwave, FM, airband, VHF, and UHF frequencies.
It also supports 10  watts transmission on the 2 meter and 70 cm amateur bands (144–148 MHz and 430–440 MHz), making it suitable for both listening and limited transmitting.
With a 70 cm Ø aluminium loop, a 95 cm long mast and a total weight of around 2 kg, the WV-601 offers a practical combination of durability and portability for both field and home use.
This antenna is characterized by it's passive, broadband, and low-noise design, making it compatible with SDR's, scanners, shortwave receivers, and other 50 ohm broadband equipment.
Constructed from durable aluminium, it features a waterproof IPX4 rating (weather-resistant) that is factory-tested, ensuring suitability for outdoor installation. The antenna performs best when mounted outdoors at height, free from obstructions.
The WV-601 undergoes strict testing before leaving the factory and is guaranteed to be ready for use upon installation. No power source needed, just install, connect, and start receiving.
