HamKing - AZ-510

Product code: 6107
Factory code: 6107
Barcode: 8718375101278

The HamKing AZ 510 is a pre-tuned mobile antenna, for best performance on 144 MHz and 430 MHz. Sometimes a minor VSWR adjustment can be useful, which can be done by moving the antenna up/down at the base end. Length: 95 cm (app. 38"). Max. power: 50 Watts.

Frequency range: 144 / 430 MHz
Shipped next business day
€25.58 (25.58 excl. 0% VAT)

Electrical data

  • Electrical type: 144 MHz: 1/2 λ radialless / 430 MHz: 2x 5/8 λ radialless
  • Gain: 144 MHz: 2.15 dBi / 430 MHz: 5.5 dBi
  • VSWR: ≤ 1.5
  • Power continues: 50 Watts
  • Impedance: 50 Ohm
  • Polarization: Linear vertical

Mechanical data

  • Height: 950 mm
  • Weight: 120 gram
  • Mounting type: On UHF-female (PL) connector (not included)
  • Antenna connector: UHF-male (PL)

Inside the box

  • Antenna: Yes
  • Installation manual: English
