HamKing - HVT-100

Product code: 6105
Factory code: 6105
Barcode: 8718375101254

The HamKing HVT-100 mobile antenna is designed for best performance on frequencies between 7 - 430 MHz. A schematic diagram is provided for the correct adjustment on the different bands.

Frequency range: 7 / 10 / 14 / 18 / 21 / 24 / 28 / 144 / 430 MHz
Shipped next business day
€57.81 (57.81 excl. 0% VAT)

Electrical data

  • Electrical type: HF: 1/4 λ reduced / 50 / 144 MHz: 1/4 λ / 144 / 430 MHz: 5/8 λ
  • VSWR: ≤ 1.5
  • Power continues: 130 Watts
  • Impedance: 50 Ohm
  • Polarization: Linear vertical

Mechanical data

  • Height: 500 - 1780 mm
  • Weight: 400 gram
  • Mounting type: On UHF-female (PL) connector (not included)
  • Antenna connector: UHF-male (PL)

Inside the box

  • Antenna: Yes
  • Installation manual: English
