K-PO - CX-201 N

Product code: 905003
Barcode: 8718375100998

The K-PO CX-201 N is a 2 way antenna switch with a N female input connector and 2x N female output connectors.

Frequency range: Up to 600 MHz
Shipped next business day
€28.88 (28.88 excl. 0% VAT)

Electrical data

  • Power continues: Max 1 kW
  • VSWR: Less than 1.2:1
  • Impedance: 50 Ohm
  • Insertion loss: Less than 0.2 dB
  • Isolation: Better than 50 dB

Mechanical data

  • Connector(s) type in: N female
  • Connector(s) type out: N female
  • Length: 90 mm
  • Height: 40 mm
  • Width: 80 mm
  • Weight: 350 gram
