K-PO - CX-201 UHF (PL)

Product code: 905004
Barcode: 8718375100981

The K-PO CX-201 UHF (PL) is a 2 way antenna switch with a UHF (PL) female input connector and 2x UHF (PL) female output connectors.

Frequency range: Up to 600 MHz
Out of stock - Longer delivery time
€24.75 (24.75 excl. 0% VAT)

Electrical data

  • Power continues: Max 1 kW
  • VSWR: Less than 1.2:1
  • Impedance: 50 Ohm
  • Insertion loss: Less than 0.2 dB
  • Isolation: Better than 50 dB

Mechanical data

  • Connector(s) type in: UHF (PL) female
  • Connector(s) type out: UHF (PL) female
  • Length: 90 mm
  • Height: 40 mm
  • Width: 80 mm
  • Weight: 350 gram
