K-PO - DG-503N

Product code: 900503
Barcode: 8718375101032

The K-PO DG-503N is a digital high quality SWR / PWR meter for accurate measuring of Forward Power, Reflected Power and SWR. The K-PO DG-503N has a frequency range from 1.6 - 60 and 125 to 525 MHz with a maximum power handling of 200 Watts.

The K-PO DG-503N is the only version with N connectors on the VHF / UHF side.

Our 'N' version has 1x UHF-female input connector and 1x UHF-female output connector for 1.6 - 60 MHz and 1x N-female input connector and 1x N-female output connector for 125 - 525 MHz.

For use with analogue and FDMA modulations. Digital meters don't always measure PEP / SSB modulations correctly, for that you need an analogue meter with PEP function, such as the K-PO RX-503N.

Frequency range: 1.6 - 60 / 125 - 525 MHz
Shipped next business day
€139.63 (139.63 excl. 0% VAT)

Electrical data

  • Backlight display / meter: Yes
  • Impedance: 50 Ohm
  • Power range: 0 - 200 Watts
  • Accuracy: ±5%
  • Minimum Power for SWR: 1 Watt
  • Insertion loss: 0.1 dB
  • Testing function: SWR and Power (FWD and REF)
  • Voltage: 13.8 Volt
  • Calibration point: 14 / 50 / 145 / 435 MHz

Mechanical data

  • Input connector: 1.6 - 60 MHz: UHF (PL) female / 125 - 525 MHz: N female
  • Output connector: 1.6 - 60 MHz: UHF (PL) female / 125 - 525 MHz: N female
  • Length: 140 mm
  • Height: 84 mm
  • Width: 122 mm
  • Weight: 750 gram

Inside the box

  • Meter: Yes
  • DC power cable: Yes
  • Installation manual: English
