K-PO - NM 452 P6

Product code: 910052

The K-PO NM 452 is a high quality power microphone to enhance audio sound. This microphone is suitable for most 6 pin CB radios. It features a slide echo control and on air indicator light. The microphone requires a 9V battery (not included).

Shipped next business day
€44.95 (37.15 excl. 21% VAT)

Features

  • Suitable for: 6-pin standard connector / Midland Alan 48 Excel / Midland Alan 48 Plus / Midland Alan 48 PRO / Midland Alan 78 Plus / Midland Alan 78 PRO / President Andy / President Barry ASC / President Barry II ASC / President Bill ASC / President Bill II ASC / President Grant II ASC / President Harrison II ASC / President Harry ASC / President Harry II ASC / President Harry III ASC / President Henry ASC / President Jackson II / President JFK II / President Jimmy II ASC / President Johnny / President Johnny ASC / President Johnny II / President Johnny III / President Johnson II / President Johnson II VOX / President Lincoln II ASC / President Lincoln II + / President Martin ASC / President MC Kinley / President Richard / President Ronald / President Taylor II Classic / President Taylor III ASC / President Taylor IV ASC / President Teddy / President Teddy II ASC / President Tommy / President Truman / President Walker / President Walker II ASC / President George II ASC /
  • Echo Function: Yes
  • Microphone type: Power microphone / Echo microphone / Electric microphone

Electrical data

  • Frequency response: 300 Hz - 6 kHz
  • Impedance: 1K Ohm (at 1 kHz)
  • Sensitivity: -42 dB (at 1 kHz)

Mechanical data

  • Cable Length: 1.8 meter
  • Battery: Standard 9 volt battery (not included).

Microphone wiring

  • Receive: Pin 2
  • Transmit: Pin 3
  • Mic Audio: Pin 1
  • Ground: Pin 5
