K-PO - NM 532 P4

Product code: 910040

Factory code: 910040

The K-PO NM 532 is a high quality power microphone to enhance audio sound. This microphone is suitable for most 4-pin CB radios that have the old President / Uniden 4-pin wiring. It features a slide volume control and on air indicator light. The microphone requires a 9V battery (not included).

Shipped today

€38.95 (32.19 excl. 21% VAT)

Features

• Suitable for: 4-pin standard connector
• Volume control: Yes

Electrical data

• Frequency response: 300 Hz - 6 kHz
• Impedance: 1K Ohm (at 1 kHz)
• Sensitivity: -42 dB (at 1 kHz)
• Microphone type: Power microphone

Mechanical data

• Cable Length: 1.8 meter
• Microphone connector: 4-pin
• Battery: Standard 9 volt battery (not included).

Microphone wiring

• Receive: Pin 4
• Transmit: Pin 3
• Mic Audio: Pin 2
• Ground: Pin 1
