K-PO - TX-502N

Product code: 600513

Barcode: 8718375103272

The K-PO TX-502N is a highly accurate SWR and power cross-needle meter for the 1.6 – 525 MHz frequency range.

Our version is with UHF-female in- and output connectors for 1.6 - 200 MHz and N-female in- and output connectors for 125 - 525 MHz.

The large cross-needle display makes it easy to read Forward Power, Reflected Power and SWR all at once.

The meter features an AVG/PEP switch to select between average power (AVG) and Peak Envelope Power (PEP), which is especially useful for SSB and AM transmissions.

The K-PO TX-502N supports up to 200 Watt of peak power (short time), ensuring reliable performance.

Made by Nissei, Taiwan.

Frequency range: 1.6 - 525 MHz

Note - Price on request

€ -- (Price on request)

Electrical data

• Backlight display / meter: Yes
• Impedance: 50 Ohm
• Power range: 2 / 20 / 200 Watts
• Accuracy: ± 10% of Full Scale or better
• Minimum Power for SWR: 1 Watt
• Insertion loss: Less than 0.1dB
• Testing function: SWR and Power (FWD and REF / AVG and PEP)
• Voltage: 9–14 VDC, 200 mA max.
• Center calibrate: 1.6-60 MHz (6m/HF) at 28.5 MHz / 140-150 MHz (2mVHF at 145 MHz / 430-440 MHz (70cm/UHF) at 435 MHz

Mechanical data

• Input connector: 1.6 - 200 MHz: UHF (PL) female / 125 - 525 MHz: N female
• Output connector: 1.6 - 200 MHz: UHF (PL) female / 125 - 525 MHz: N female
• Weight: 1070 gram
• Width: 184 mm
• Height: 118 mm
• Depth: 131 mm

Inside the box

• Meter: Yes
• DC power cable: Yes
• Installation manual: English
