Maas - SPS-9600

Product code: 9600

Barcode: 4250158700567

The Maas SPS-9600 is a high power switching mode. They are suitable for a wide range of uses, such as radio equipment. The power supply has a variable output from 1 to 15 Volt. The SPS-9600 can be used for equipment till 60A continuous.

Out of stock - Longer delivery time

€419.94 (347.06 excl. 21% VAT)

Electrical data

• Input voltage: 230 Volt / 50 Hz /
• Output voltage: 13.8 Volt
• Adjustable output voltage: 1-15 Volt
• Continuous load: 60A
• Ripple voltage: ≤40mVp-p
• Display indicator: Voltage / ampère
• Background light: Yes
• Fan: Yes
• Short circuit protection: Yes
• Overload protection: Yes
• Rated output power: 900W
• Cooling method: Thermostatic control fan

Mechanical data

• Length: 220 mm
• Height: 110 mm
• Width: 360 mm
• Weight: 5800 gram

Inside the box

• Power supply: Yes
• AC cord: Yes
• User manual: English

Downloads

• Datasheet: User manual
