Manson - SDC 5330

Product code: 2171

The Manson SDC 5330 is a voltage reducer from 19-33V to 13.8V DC power and has an continuous/peak output of 30A. Connection is via screw terminals (no cable included). The SDC 5330 is a new serie of non-isolated digital DC-DC step down converter with micro-processor control for fine adjustment of output voltage to optimally suit the loading condition. The 3 digit LED display shows: output voltage, current, operation mode and fault status.

Out of stock - Longer delivery time

Available from - 08-10-2026

€69.95 (57.81 excl. 21% VAT)

Electrical data

• Input power: 19 - 33 Volt
• Output voltage: 13.8 Volt
• Continuous output current: 30 A
• No load current: <40mA
• Efficiency: <90%
• Protections: OVP,OTP,Overload,Input Reverse Polarity,Output Short Circuit Protection
• Cooling system: Thermostatic control fan
• Max operating temperature: -10°C to +50°C
• Approvals: EN 55014
• Adjustable output voltage rangr: 12 - 15 Volt
• Battery charger mode: Yes
• Output remote on/off control: Yes
• Voltage remote sense: Yes
• Display: 3 digit LED display

Mechanical data

• Length: 130 mm
• Height: 55 mm
• Width: 180 mm
• Weight: 1200 gram

Inside the box

• Voltage reducer: Yes
• User manual: English

Downloads

• Datasheet: 5360 user manual
