Manson - SPA-8250

Product code: 8220

The Manson SPA-8250 is a very compact en silent power supply. The SPA-8250 can be used for equipment till 25A continuous.

Note - Discontinued

€ -- (Discontinued)

Electrical data

• Input voltage: 230 Volt / 50 Hz /
• Output voltage: 13.8 Volt
• Continuous load: 25A
• Ripple voltage: ≤50mVp-p
• Fan: Yes
• Short circuit protection: Yes
• Overload protection: Yes
• Rated output power: 345 Watts
• Cooling method: Thermally control fan cool

Mechanical data

• Length: 220 mm
• Height: 110 mm
• Width: 220 mm
• Weight: 2700 gram

Inside the box

• Power supply: Yes
• AC cord: Yes
• User manual: English

Downloads

• Datasheet: User Manual 8250
