Nissei - NS-1228

Product code: 2150

Barcode: 8718375103524

The Nissei NS-1228 is a compact switching power supply with fixed 13.8 VDC output, up to 25A continuous and 28A peak.

It supports both 110 and 230 VAC input (switch on the back) and includes short circuit and over voltage protection.

Shipped today

€119.95 (99.13 excl. 21% VAT)

Electrical data

• Input voltage: 110 Volt / 230 Volt /
• Output voltage: 13.8 Volt (fixed)
• Continuous load: 25A
• Peak load: 28A
• Ripple voltage: Peak to peak ripple and noise less than 0.3%
• Fuse: 6.3A
• Fan: Yes
• Short circuit protection: Yes
• Input frequency: 47 - 63 Hz
• Overvoltage protection (limited): 16V ±0.5V

Mechanical data

• Length: 230 mm
• Height: 55 mm
• Width: 180 mm
• Weight: 1800 gram

Inside the box

• Power supply: Yes
• AC cord: Yes
• User manual: English
