Nissei - NS-1228A

Product code: 2151
Barcode: 8718375103531

The Nissei NS-1228A is a switching power supply with adjustable 9–15 VDC output, up to 25A continuous and 28A peak and 110 and 230 VAC input (switch on the back).

It features precision voltage regulation, low ripple of less than 0.3%, and binding post output terminals for secure connections.

Equipped with short circuit and over voltage protection, an external fuse, and high surge capacity, it ensures reliable operation for demanding equipment.

A heavy-duty metal cabinet with a powder-coated finish houses the unit, with dual backlit meters for clear voltage and current (A) monitoring.

Shipped today
€139.95 (115.66 excl. 21% VAT)

Electrical data

  • Input voltage: 110 Volt / 230 Volt /
  • Output voltage: 13.8 Volt
  • Adjustable output voltage: 9-15V adjustable
  • Continuous load: 25A
  • Peak load: 28A
  • Ripple voltage: Peak to peak ripple and noise less than 0.3%
  • Background light: Yes
  • Fan: Yes
  • Short circuit protection: Yes
  • Input frequency: 47 - 63 Hz
  • Overvoltage protection (limited): 16V ±0.5V

Mechanical data

  • Length: 170 mm
  • Height: 110 mm
  • Width: 145 mm
  • Weight: 1800 gram

Inside the box

  • Power supply: Yes
  • AC cord: Yes
  • User manual: English
