President - Alaska S

Product code: 200201
Factory code: AMMI736
Barcode: 3435992105100

The Alaska S is a high-performance 5/8 wave fixed mobile antenna, delivering +6 dBi gain and capable of handling up to 400 W P.E.P. Its compact design (1480 mm, 0.2 kg) makes it ideal for mobile installations, while the AC4 stainless steel construction ensures durability and long-lasting performance. Compatible with Type LS-06 mounts. (UHF)

Key Specifications:

  • Wave: 5/8
  • Impedance: 1,1/1
  • Gain: +6 dBi
  • Power: 400 W P.E.P
  • Frequency: 1200 kHz
  • Weight: 0.200 kg
  • Length: 1480 mm
  • Material: AC4 Stainless Steel
  • Mount Type: LS-06 (UHF)
Frequency range: 26.0 - 28.0 MHz
Shipped next business day
€59.94 (49.54 excl. 21% VAT)

Electrical data

  • Electrical type: 1/2 wave
  • Gain: 6 dBi
  • VSWR: 1,1 / 1 adjustable
  • Bandwidth: 1200 kHz
  • Power peak: 400 Watts (P.E.P.)
  • Impedance: 50 Ohm
  • Polarization: Linear vertical
  • Cable: Yes
  • Cable length: 4.5 meter / RG 58

Mechanical data

  • Materials: AC4 Stainless steel
  • Height: 1480 mm
  • Weight: 300 gram
  • Mounting type: Thru-hole
  • Antenna connector: FME female

Inside the box

  • Antenna: Yes
  • Radio connector: UHF-male (PL)
  • Mounting parts: Yes
  • Antenna cable: Yes
  • Installation manual: English
