President - Richard II

Product code: 80094

The President Richard II is a powerful and modern transceiver that stands for reliability, performance, and ease of use. As the successor to the successful President Richard, this model builds on a proven foundation while offering modern enhancements. It features updated technology, improved power control, and a more user-friendly interface, delivering excellent audio quality and stable communication even under demanding conditions.

Just like other President models, the Richard II is equipped with NRC (Noise Reduction Circuit) and new filters, providing clearer reception and better signal quality. With its well-thought-out design and advanced features, it is the ideal choice for both experienced radio amateurs and serious users who want to take their communication to the next level, whether in mobile or fixed installations.

Frequency range: 24.890 - 24.990 / 28.000 - 29.700 MHz
Note - Price on request
€ -- (Price on request)

Features

  • Modulation: AM / FM
  • Output power: AM: 13 Watt / FM: 40 Watt
  • Display type: LCD display
  • Display colors: Green / Orange / Purple / Blue / Cyaan / Yellow / Clear Blue
  • Export version: 26.965 - 30.105 MHz
  • VOX Function: Yes
  • USB: Yes
  • Noise blanker: Yes
  • Squelch: ASQ (Automatiq Squelch Systeem) / Manual squelch /
  • Emergency channel: Yes
  • Hi/Lo power: Yes
  • Scan function: Yes
  • Memory channels: Yes
  • External speaker socket: Yes
  • External PA socket: Yes
  • S-meter: Yes
  • MIC gain: Yes
  • RF gain: Yes
  • TOT (time out timer): Yes
  • External VOX socket: Yes
  • Roger Beep: Yes

Electrical data

  • Voltage: 13,8 Volt

Transmitter

  • Frequency allowance: ± 300 Hz
  • Carrier power: 13W AM (± 50W PEP) / 40W FM
  • Transmission interference: inferior to -50 dBm
  • Audio response: 300 Hz to 3 kHz AM/FM
  • Emitted power in the adjacent channel: inferior to 20 μW
  • Microphone sensitivity: 3.0 mV
  • Drain: 7A max (with modulation)
  • Modulated signal distortion: 2 %

Receiver

  • Max sensitivity at 20 dB sinad: 0.7 µV - 110 dBm (AM) / 0.35 µV - 116 dBm (FM)
  • Frequency response: 300 Hz to 3 kHz (AM/FM)
  • Adjacent channel selectivity: 60 dB
  • Maximum audio power: 3W
  • Squelch sensitivity: min 0.2 μV - 120 dBm / max 1 mV - 47 dBm
  • Frequency image rejection rate: 60 dB
  • Intermediate image rejection rate: 70 dB
  • Drain: max 500 mA

Mechanical data

  • Length: 190 mm
  • Height: 55 mm
  • Width: 185 mm
  • Weight: 1100 gram
  • Antenna connector: UHF (PL) female (SO-239)
  • Mike connector: 6 pin connector

Inside the box

  • Transceiver: 1 pcs
  • Microphone: 1 pcs
  • Fixing screws: 1 set
  • Mounting bracket: 1 pcs
  • Power lead: 1 pcs
  • User Manual: English, Spanish, French, Polish
