Quansheng - TK-11(8) Quansheng - TK-11(8) Quansheng - TK-11(8) Quansheng - TK-11(8) Quansheng - TK-11(8) Quansheng - TK-11(8)

Quansheng - TK-11(8)

Product code: 46011
Factory code: 46011

Our Quansheng TK-11(8) is the fully featured European version of this multi-band handheld transceiver, with English language and a wide range of practical and entertaining features. Please note that versions sold via Chinese websites are usually in Chinese only and cannot be updated to the European English version.

It supports SSB, AM, and FM receiving and offers dual-channel reception. With an output power of up to 10W, the TK-11(8) provides stable and clear communication over longer distances. The 3000 mAh battery provides a long operating time, making it ideal for longer sessions and use during field days.

Some of the other key features are:

  • Wide band receiving: 0.153–1160 MHz
  • Transmit bands: 25–29.8 MHz, 50–54 MHz, 144–146 MHz, 430–440 MHz
  • Magic Voice; infantlike and alien voice
  • 999 memory channels
  • Cross-band repeater capability
  • Spectrum analyzer, frequency meter
  • Support for DTMF, 1750 Hz call tone, 5-Tone, CTCSS/DCS

You can find all details and features in the leaflet available in the 'Downloads' section at the bottom of this product page.

European version with CE (RED) certification.

Frequency range: TX: 25-29.8 MHz / 50-54 MHz / 144-146 / 440-440 MHz / RX: 0.153 - 1160 MHz
Out of stock - Longer delivery time
Available from - 10-07-2025
€79.99 (66.11 excl. 21% VAT)

Features

  • Display: Yes, large LCD display
  • VOX function: Yes
  • DTMF: Yes, and 1750 tone
  • 2-tone/5-tone: 5 Tone Select call
  • Crossband repeater function: Yes
  • Emergency (SOS) function: Yes
  • High/low power selection: H/M/L Output Power Selective
  • Battery capacity: 3000 mAh (7,4 V)
  • Accessory connector: 2-pin Kenwood connector (K)
  • USB-C connector: Yes, can be used for charging
  • Password protection: Yes
  • CTCSS/DCS: Yes
  • Scan: Yes
  • Spectrum Analyzer: Yes

Electrical data

  • Frequency step: 12.5 kHz / 25 kHz /
  • Channels: 999 Memory channels / 32 Stored FM radio channel quantity
  • Wide and narrow bandwidth selection: Yes
  • Operating temperature: -20℃ to +60℃
  • Frequency stability: ±1.0 PPM

Transmitter

  • Power output (Watts): 10 Watts
  • Modulation limit: FM:11KOF3E(12.5KHz),16KOF3E(25KHz)
  • Adjacent channel power: 12.5 kHz: 60 dB / 25 kHz: 70 dB
  • Audio distortion: ≤5%
  • Max. frequency deviation: 12.5 kHz: ≤2.5 kHz / 25 kHz: ≤5 kHz
  • Stray power: ≤7.5 uW
  • Residual modulation: 40 dB
  • Emission current: ≤2.5 A

Receiver

  • Audio frequency: ≥0.5 W
  • Audio distortion: ≤10%

Mechanical data

  • Length: 58 mm
  • Height: 126 mm
  • Width: 34.5 mm
  • Weight: 289 gram
  • Antenna connector: SMA male

Inside the box

  • Transceiver: Yes
  • Battery: 3000 mAh
  • Charger: Desk charger with adapter
  • Antenna: Yes
  • Installation manual: English
  • Belt clip: Yes
  • Hand strap: Yes
