Sirio - CX 840 N-f

Product code: 210740100
Factory code: 2107401.00
Barcode: 8056182115652

UHF antennas for base station service made of high quality materials to get the best performance and the maximun efficiency. They are completely manufactured with aluminium tubes and thermoplastic UV stabilized for its great robustness and supplied with a solid steel bracket for an easy and safe installation. They are DC-grounded for a perfect protection against the discharges and no tuning is required. Simple and strong, they are particularly recommended for a professional use.

Frequency range: TX: 824 - 894 MHz
Out of stock - Longer delivery time
€49.95 (41.28 excl. 21% VAT)

Electrical data

  • Electrical type: 3/4 λ coaxial J-pole
  • Gain: 0 dBd, 2.15 dBi
  • VSWR: TX: 824 - 849 MHz ≤ 1.6 / RX: 869 - 894 MHz: ≤ 2.8
  • Maximum continuous power: 100 Watts (CW)
  • Impedance: 50 Ohm
  • Polarization: Linear vertical

Mechanical data

  • Materials: Aluminium, brass, galvanized steel, zamak
  • Mast Ø: 35 - 42 mm
  • Max wind resistance: 180 km/h
  • Height: 390 mm
  • Weight: 470 gram
  • Mounting type: On mast
  • Antenna connector: N-female

Inside the box

  • Antenna: Yes
  • Mounting parts: Yes
  • Installation manual: English
