Sirio - GP 365-470 C

Product code: 2102105

Factory code: 2102105.00

Barcode: 8056182113122

UHF colinear Ground Plane antenna suitable for the base station service covering the frequency range of 365 - 470 MHz tunable by cutting. The main whip and the radials are made of 17/7 PH stainless steel and its base is of chromed brass to get the best robustness. Easy to fit, it is suitable for a handy installation everywhere.

Frequency range: 365 - 470 MHz tunable

Out of stock - Longer delivery time

€63.95 (52.85 excl. 21% VAT)

Electrical data

• Electrical type: 1/4 λ + 1/2 λ colinear
• Gain: 2.5 dBd, 4.65 dBi
• VSWR: ≤ 1.2
• Bandwidth: 15 MHz ≤ 1.5
• Maximum continuous power: 150 Watts (CW)
• Impedance: 50 Ohm
• Polarization: Linear vertical

Mechanical data

• Materials: Aluminium, brass, stainless steel 17/7 PH
• Mast Ø: 35 - 54 mm
• Max wind resistance: 180 km/h
• Height: 990 mm
• Weight: 729 gram
• Mounting type: On mast
• Antenna connector: N-female 'Gold Plated'

Inside the box

• Antenna: Yes
• Mounting parts: Yes
• Installation manual: English

Downloads

• Datasheet: Id 061 gp365 470c 13 04 2006
