Sirio - GP 430 LB-N

Product code: 210370100
Factory code: 2103701.00/N
Barcode: 8056182113283

1/4 λ wide-band antenna for base station service covering the frequency range of 380-480 MHz. It as been developed according to the most modern technologies to assure a perfect protection against the worst atmospheric climates and to get the best performance. It is entirely made of aluminium to assure strength and robustness and its radial whip is earthed.

Frequency range: 380 - 480 MHz
Shipped next business day
€74.34 (74.34 excl. 0% VAT)

Electrical data

  • Electrical type: 1/4 λ ground plane
  • Gain: 0 dBd, 2.15 dBi
  • VSWR: ≤ 1.7
  • Power continues: 300 Watts (CW)
  • Impedance: 50 Ohm
  • Polarization: Linear vertical

Mechanical data

  • Materials: Anodized aluminium, stainless steel, nylon
  • Mast Ø: 36 - 40 mm
  • Max wind resistance: 180 km/h
  • Height: 295 mm
  • Weight: 830 gram
  • Mounting type: On mast
  • Antenna connector: N-female 'Gold Plated' central pin

Inside the box

  • Antenna: Yes
  • Mounting parts: Yes
  • Installation manual: English

Downloads
