Sirio - HGO 433-868 Cable

Product code: 21541045

Factory code: 2154104/5CO

Barcode: 8056182111913

Dual-band omni-directional base station antenna conceived to work on 433 and 868 MHz (ISM/LoRa systems). It is protected by thermoplastic UV stabilized material for the best robustness and long life for outdoor and indoor installations. It is supplied with plastic bracket and fixing hardware for an easy installation on the mast or on the wall and it comes with 5 meter low loss cable with SMA-male connector.

Frequency range: 415 - 465 / 815 - 890 MHz

Out of stock - Longer delivery time

€79.94 (66.07 excl. 21% VAT)

Electrical data

• Electrical type: Multi band dipole array
• Gain: 433 MHz: 2 dBi / 868 MHz: 4 dBi
• VSWR: See the product manual under downloads
• Maximum continuous power: 20 Watts (CW)
• Impedance: 50 Ohm
• Polarization: Linear vertical
• Cable: Yes
• Cable length: 5 meter / White low loss

Mechanical data

• Materials: Galvanized steel, thermoplastic UV stabilized, PCB
• Mast Ø: 25 - 42 mm
• Max wind resistance: 200 km/h
• Length: 166 mm
• Height: 355 mm
• Width: 144 mm
• Weight: 350 gram
• Mounting type: On mast, on wall

Inside the box

• Antenna: Yes
• Radio connector: SMA-male
• Mounting parts: Yes
• Antenna cable: Yes
• Installation manual: English

Downloads

• Datasheet: Id 413 04 10 2011 HGO433 868
