Sirio - Hi-Power 4000 N

Sirio - Hi-Power 4000 N

Product code: 4000
Factory code: 2202505.23
Barcode: 8056182114068

The Sirio Hi-Power series are one of the most popular high power antennas. Easy installation and with anti-theft safety key.

Frequency range: 27 - 30 MHz
Out of stock - Longer delivery time
€52.02 (52.02 excl. 0% VAT)

Electrical data

  • Electrical type: Base loaded
  • VSWR: ≤ 1.2
  • Bandwidth: 2580 kHz (230 channels) ≤ 2.0
  • Power continues: 600 Watts (CW)
  • Power peak: 1200 Watts (CW)
  • Impedance: 50 Ohm
  • Polarization: Linear vertical
  • Cable: Yes
  • Cable length: 4 meter / RG 58

Mechanical data

  • Materials: Copper, brass, stainless steel 17/7 PH, nylon
  • Height: 2030 mm
  • Weight: 450 gram
  • Mounting type: Thru-hole

Inside the box

  • Antenna: Yes
  • Radio connector: Not included, optional
  • Mounting parts: Yes
  • Antenna cable: Yes
  • Installation manual: English, Italian

Downloads
